CSM RO membrane RE2521-BLN (300GPD)

Manufacturer: none

Product SKU: RE2521-BLN

Price including VAT € 143.84

Price excluding VAT € 116.00

Product is in stock

Delivery time: 2-5 working days

Have questions?

Contact our specialists.

Description

Technical data

Attachments

RE 2521-BLN
Low pressure grade RO element for brackish water

SPECIFICATIONS

General Features:

Permeate flow rate: 300 GPD ( 1.1 m3/day)
Stabilized salt rejection: 99.2%
Effective membrane area: 12 ft2 (1.1 m2)
Membrane type: Thin-Film Composite
Membrane material: Polyamide(PA)
Element configuration: Spiral-Wound, FRP Wrapping

APPLICATION DATA

Operating Limits:

Max. Pressure Drop / Element - 15 psi (0.1 MPa)
Max. Pressure Drop / 240” Vessel - 60 psi (0.41 Mpa)
Max. Operating Pressure - 600 psi (4.14 MPa)
Max. Feed Flow Rate - 6 gpm (1.36 m3/hr)
Min. Concentrate Flow Rate - 1 gpm (0.23 m3/hr)
Max. Operating Temperature - 113 oF (45 oC)
Operating pH Range - 2.0–11.0
CIP pH Range 1.0–13.0
Max. Turbidity - 1.0 NTU
Max. SDI (15 min) - 5.0
Max. Chlorine Concentration < 0.1 mg/L

Design Guidelines for VariousWater Sources:

Wastewater Conventional (SDI < 5) - 8–12 gfd
Wastewater Pretreated by UF/MF (SDI < 3) - 10–14 gfd
Seawater, Open Intake (SDI < 5) - 7–10 gfd
Seawater, Beach Well (SDI < 3) - 8–12 gfd
Surface Water (SDI < 5) - 12–16 gfd
Surface Water (SDI < 3) - 13–17 gfd
Well water (SDI < 3) - 13–17 gfd
RO permeate (SDI < 1) - 21–30 gfd

Saturation Limits (Using Antiscalants) *:

Langlier Saturation Index (LSI) <+1.5
Stiff and Davis Saturation Index (SDSI) <+0.5
CaSO 4 - 230% saturation
SrSO4 - 800% saturation
BaSO4 - 6,000% saturation
SiO2 - 100% saturation

*The above saturation limits are typically accepted by proprietary antiscalant manufacturers. It is the user’s responsibility to ensure proper chemical(s) and
concentration are dosed ahead of the membrane system to prevent scale
formation anywhere within the membrane system. Membrane elements fouled or damaged due to scale formation are not covered by the limited warranty.
