Motorized Alternating Valve 2 BSPT Revision 2 (Piston Style)
Tarneaeg: 2-5 tööpäeva
2” NPT or 2” BSPT Available
Epoxy coated lead free brass valve body*
Allows for two WS2, WS2L or WS2H Valves to be a Twin Alternating System
Full 2” ports with minimal pressure loss
Provides for no raw water bypass during regeneration
Provides choices of treated or non-treated water regeneration
Proven and reliable Clack DC drive assembly
Low voltage drive assembly controlled by valve’s circuit board
Flow from Port A to Common has a 2.1 PSI drop at 90 GPM
Flow from Port B to Common has a 1.4 PSI drop at 90 GPM
Hydraulically Balanced Piston Valve
Patented Seal/Spacer Stack Assembly
Operating Pressures (min/max): 1,4 bar/ 8,6 bar
Operating Temperatures(min/max): 4C/43C
| Laius (cm) | Kõrgus (cm) | Pikkus (cm) | Kaal (kg) |
|---|---|---|---|
| 20 | 15 | 30 | 2.8 |
