WS3'' No Hard Water Bypass MalexFemale NPT
Tarneaeg: 2-5 tööpäeva
3” NPT and 3” BSPT
Lead Free Brass Casting with NSF/FDA approved black coating
Hydraulically balanced piston valve
Allows for two WS3 Valves to be a Twin Alternating System or multiple tank system
Full 3” ports with minimal pressure loss
Provides for no raw water bypass during regeneration
Provides choices of treated or non-treated water regeneration
Proven and reliable Clack DC drive assembly
Low voltage drive assembly controlled by valve’s circuit board
Flow from Port A to Common has a 3.1 PSI drop at 250 GPM
Flow from Port B to Common has a 2.3 PSI drop at 250 GPM
Flow from Port A to Port B was a 5 psi drop at 250 GPM
Operating Pressures (min/max): 1.4 bar/8.6 bar
Operating Temperatures (min/max): 4Co/ 43oC
| Laius (cm) | Kõrgus (cm) | Pikkus (cm) | Kaal (kg) |
|---|---|---|---|
| 20 | 15 | 30 | 4 |
