Automaatklapp 1.5 BSPT Revision 2
Toode on laos olemas
Tarneaeg: 2-5 tööpäeva
1.5” NPT or 1.5” BSPT Available
Epoxy coated lead free brass valve body*
Allows for two WS1.5 Valves to be a Twin Alternating System
Full 1.5” ports with minimal pressure loss
Provides for no raw water bypass during regeneration
Provides choices of treated or non-treated water regeneration
Proven and reliable Clack DC drive assembly
Low voltage drive assembly controlled by valve’s circuit board
Flow from Port A to Common has a 3.74 PSI drop at 60 GPM
Flow from Port B to Common has a 2.15 PSI drop at 60 GPM
Hydraulically Balanced Piston Valve
Patented Seal/Spacer Stack Assembly
Operating Pressures (min/max): 1,4 bar/ 8,6 bar
Operating Temperatures(min/max): 4C/43C
Tootefotod on illustratiivsed. Toote välimus ja konfiguratsioon võivad erineda, ilma et see mõjutaks toote tehnilisi omadusi või funktsionaalsust.
| Laius (cm) | Kõrgus (cm) | Pikkus (cm) | Kaal (kg) |
|---|---|---|---|
| 20 | 15 | 30 | 1.4 |
