Dosing pump AUREX A MF 7-10 220/240V PVDF
Product is in stock
Delivery time: 2-5 working days
AUREX MF is a multifunction solenoid dosing pump with a microprocessor and display, enabling precise selection of injection pulses.
The maximum flow rate and operating pressure can be set by the user.
Main features:
- Provision for level probe (probe not included).
- Operating modes: proportional and ON/OFF; proportional dosing from counter: 1×n; 1×n (m); 1:n; ml×P; l×P; ml×m³; PPM; adjustable 4–20 mA control.
- Alarm relay output.
- Daily and weekly timer.
- Priming function.
- 4 languages: Italian, English, French, Spanish.
- Passcode protection.
- Acid-resistant housing (PP).
- Protection rating: IP65.
- Max. flow rate: 50 l/h; max. back pressure: 20 bar.
- Wall or floor mounting with bracket (not included).
- Configuration: PVDF head, PTFE diaphragm, FPM seals, ceramic ball valves*.
- Head with manual bleed: from 2 to 50 l/h.
- Standard power supply: 220–240 V.
- 3 different flow rates selectable by the user.
Product photos are for illustrative purposes only. The product’s appearance and configuration may vary without affecting its technical specifications or functionality.
Model | Flow rate l/h (US gal/h) | Pressure bar (PSI) | Max frequency (strokes/min) | Injection volume (cc/stroke) | Power supply | Weight (kg) |
AUREX A MF | 8 (2.12) | 7 (102) | 150 | 0.89 | 220–240V 50–60Hz | 2.3 |
10 (2.64) | 5 (72.5) | 170 | 0.98 | 220–240V 50–60Hz | 2.3 | |
20 (5.28) | 2 (29) | 250 | 1.33 | 220–240V 50–60Hz | 2.3 |
| Width (cm) | Height (cm) | Length (cm) | Weight (kg) |
|---|---|---|---|
| 17.5 | 20 | 30.5 | 3.2 |
By clicking on the following link, you can view and download the following:
Etatron AUREX MF solenoid dosing-pump English-language technical data sheet (PDF)
